德国ROWNSON朗森音响 A15线阵+KS28远程低音炮 酒吧音箱 电音打碟高端配置

Description 2-way passive constant curvature WST 10°, amplified by LA4X / LA8 / LA12X Usable bandwidth (-10 dB) 41 Hz - 20 kHz ([A15]) Maximum SPL1 144 dB ([A15]) Nominal directivity Enclosure: 10° Panflex: 70°/110° symmetric or 90° asymmetric Transducers LF: 1 × 15’’ neodymium cone driver HF: 1 × 3’’ diaphragm neodymium compression driver Acoustical load LF: Bass-reflex, L-Vents HF: DOSC waveguide, Panflex Nominal impedance 8 Ω Connectors IN: 1 × 4-point speakON LINK: 1 × 4-point speakON Rigging and handling Flush-fitting two-point rigging system 2 handles, 8 corner stops and 2 ground runners Safety 1 DIN580-compatible M8 insert Weight (net) 35 kg/77 lb Cabinet Premium grade Baltic beech and birch plywood Front Coated steel grill Acoustically neutral 3D fabric Rigging components High grade steel with anti-corrosion coating Finish Dark grey brown Pantone 426 C IP IP55

技术参数

描述 被动二分频固定曲率 WST 30°，使用

LA4X / LA8 / LA12X功放驱动

可用频响范围 (-10 dB) 42 Hz - 20 kHz ([A15])

最大声压级 1 141 dB ([A15])

标称指向性 箱体: 30°

Panflex: 对称的70° / 110° 或 非对称的90°

换能器 LF: 1 × 15’’钕制锥形驱动器

HF: 1 × 3’’振膜钕制压缩驱动器

声学负载 LF: 低频反射, L-Vents

HF: DOSC 波导管, Panflex

标称阻抗 8 Ω

接插口 IN: 1 × 4-point speakON

link: 1 × 4-point speakON

吊挂和把手 集成的两点吊挂系统

2个把手、8个角垫和2个底部垫脚

安全保护 1个DIN580-兼容的M8 螺纹插孔

重量(净重） 33 kg/73 lb

箱体材料 优质波罗的海榉木和桦木胶合板

正面材料 电镀钢网

通透的声学3D织物

吊挂配件 镀有防腐涂层的优质钢

颜色 深灰棕 潘通426C

IP防护等级 IP55

1-最大声压级是采用预设参数，在自由场条件下，以1m为基准并使用峰值因数4的粉噪所测得（括号中为特定的预设）。

A15线阵音箱

KS28远程低音炮

Description  Flyable subwoofer 2 × 18’’, amplified by LA12X Low frequency limit (-10 dB) 25 Hz ([KS28_100]) Maximum SPL2 143 dB ([KS28_100]) Directivity Standard or cardioid Transducers 2 x 18’’ neodymium, aluminium die cast basket Acoustical load  Bass-reflex enclosure, L-Vents Nominal impedance 4 Ω Connectors IN: 4-point speakON® Rigging and handling Flush-fitting 2-point rigging system 6 ergonomic handles 2 ground runners 8 side runners Weight (net) 79 kg / 174 lbs Cabinet Premium grade beech and birch plywood Front Steel grill with anti-corrosion coating Acoustically neutral 3D fabric Rigging components High grade steel Finish Dark grey brown PANTONE® 426C

纯进口分频器元器件
